Refacing Methods

What is a Refacing Method? Reface·Method / ‘ree-feys, meth-uhd’ [n]: an approach to cabinet refacing based upon the combination of materials selected and how they are applied to a cabinet refacing project. WalzCraft’s Cabinet Refacing System utilizes four distinct Refacing Methods. Material Options include: PSA and Non PSA Veneers Veneer and MDF Core Plywoods 3D Laminate / RTF Sheet Goods Solid Wood Refacing Stock

Choosing a Refacing Method Which material you choose for the sides and/or the fronts will be determined by the following factors: The condition of the existing cabinet sides and fronts. Your preferences based on knowledge and experience. Your customer’s preferences based on knowledge or experience. Space limitations The desired appearance of the corners where sides and fronts meet. Restrictions because of particular species, grades, or finish choices.

Click the images below to learn more about each Refacing Method offered by WalzCraft.

Refacing Method 101 (RM101) – Veneer Face (Front) / Plywood Side



Description

Refacing Method 101 (RM101) utilizes wood veneer on the face/fronts and plywood on the sides of the cabinet.

Materials
For the sides, this method can be used with either 1/8″ or 1/4″ plywood with either a veneer core or MDF core. For the face, this method can be used with either Paper Back, Wood Back or Phenolic Back Wood Veneer.

Corner Treatment Options

• FOJS (Finish on Job Site) – If choosing not to use an Outside Corner Molding, the raw edge will need to be finished on the job site during installation.

• Outside Corner Molding Options – There are numerous options that can be added as an alternative to the FOJS Outside Corner Treatment shown.

*Please note that some moldings can only be used with certain thicknesses of refacing material.

Advantages This method provides a custom cabinet look at the outside corners. There is only a thin line on exposed edges, which requires less finish work. There is less dust created on the job site (your customer’s home). Stile/Rail strips can be easily cut right on the job site.

Disadvantages Corners are susceptible to damage when using the FOJS Corner Treatment Option (no outside corner molding applied). It is necessary to order separate types of material for the sides and fronts of the cabinet. This method requires more face frame preparation than other methods using thicker materials. This method is not the ideal choice if the existing face frames are in rough condition.

Back to Top ▲

Refacing Method 102 (RM102) – Plywood Face (Front) / Plywood Side



Description

Refacing Method 102 (RM102) utilizes plywood on both the face (front) and sides of the cabinet.

Materials

This method can be used with either 1/8″ or 1/4″ plywood with either a veneer core or MDF core.

Corner Treatment Options

• FOJS (Finish on Job Site) – If choosing not to use an Outside Corner Molding, the raw edge will need to be finished on the job site during installation.

*Please note that the raw edge of veneer core and MDF core plywood will stain up darker than the face of the veneer. This method is not recommended when using a SolidTone® finish.

• Outside Corner Molding Options – There are numerous options that can be added as an alternative to the FOJS Outside Corner Treatment shown.

*Please note that some moldings can only be used with certain thicknesses of refacing material.

Advantages This method utilizes the same material for the entire job, which simplifies the ordering process. Utilizing the same material for the entire project also enables the most efficient use of your materials. The condition of the existing face frames is less critical with this method. This method generally has the lowest material cost.

Disadvantages It may be necessary to create dust on the job site (your customer’s home) if pieces are cut oversize. There is a thicker visible core of plywood that is exposed at the edges. This method requires more time for finish work on the exposed edges. There are challenges with the FOJS option with this method that may require an outside corner molding treatment. This method provides the least perfect color/grain match between face frames and doors & door fronts.

Back to Top ▲

Refacing Method 103 (RM103) – Veneer Face (Front) / Veneer Side



Description

Refacing Method 103 (RM103) utilizes wood veneer on both the face (front) and sides of the cabinet.

Materials

This method can be used with either Paper Back, Wood Back or Phenolic Back Wood Veneer.

Corner Treatment Options

• FOJS (Finish on Job Site) – If choosing not to use an Outside Corner Molding, the raw edge will need to be finished on the job site during installation.

*Please note that this method is not recommended when using a SolidTone® finish.

• Outside Corner Molding Options – There are numerous options that can be added as an alternative to the FOJS Outside Corner Treatment shown.

*Please note that some moldings can only be used with certain thicknesses of refacing material.

Advantages This method creates a custom cabinet look at the outside corners. There is only a thin line exposed at the edges, which requires less finish work. Less dust is created on the job site (your customer’s home). Stile/Rail strips can be easily cut right on the job site. It is possible to use the same material on the entire job, making your ordering process easier & more efficient.

Disadvantages Corners are susceptible to damage when using the FOJS Corner Treatment Option (no outside corner molding applied). This method requires more meticulous preparation for the sides of the cabinets than if using plywood. This method requires more face frame preparation than other methods using thicker materials. This method is not the ideal choice if the existing face frames are in rough condition.

Back to Top ▲

Refacing Method 104 (RM104) – Solid Wood Face (Front) / Plywood Side



Description

Refacing Method 104 (RM104) utilizes Solid Wood Refacing Stock on the face/fronts and plywood on the sides of the cabinet.

Materials

For the sides, this method can be used with either 1/8″ or 1/4″ plywood with either a veneer core or MDF core. For the face, Solid Wood Refacing Stock is available in 1/8″, 3/16″, 1/4″, 5/16″ & 3/8″ thicknesses.

Corner Treatment Options

• PRFN (Pre-Finished) – When choosing to have Solid Wood Refacing Stock pre-finished by WalzCraft, one (1) face and all edges will be finished. The back side is left raw for proper glue adhesion.

*This method is not recommended when using a SolidTone® finish.

• Outside Corner Molding Options – There are numerous options that can be added as an alternative to the PRFN Outside Corner Treatment shown.

*Please note that some moldings can only be used with certain thicknesses of refacing material.

Advantages This method creates durable corners, even without a corner molding treatment. This method allows for fast installation if the order is accurately placed. This method requires very little finish work on exposed edges. This method can provide a perfect match between face frame and door & drawer fronts.

Disadvantages This method has a higher cost of materials. This method requires a detailed measuring system prior to placing an order as precise sizes are necessary. This method diminishes installation flexibility (due to precise part sizes), unless extra material is ordered.
