Nexus Cabinet Doors

Nexus Cabinet Door in Kitchen

Nexus Cabinet Doors & Drawer Fronts

WalzCraft’s Nexus Doors and Drawer Fronts offer a fresh take on the classic shaker style with narrower stiles and rails. This design is known in the cabinet industry as a Slim Shaker, Skinny Shaker, or Thin Shaker. Our version includes a variety of square, beaded, and beveled profiles that range from 1/4″ to 1 1/2″ wide.

Nexus Cabinet Doors have solid wood stiles, rails, and outside edge applied molding with mitered corners. The flat center panel is 1/2″ thick and is available in plywood or MDF for painted products. Nexus is also available with our Reeded (Beaded) Applied Molding applied to the face of the door.

WalzCraft created the Nexus Cabinet Door and Drawer Front options with a wide range of design flexibility. Whether you are looking for a minimalist slim shaker or a detailed reeded accent door, we have you covered.

LEARN MORE ABOUT NEXUS FLAT PANEL DOORS

Nexus Flat Panel Slim Shaker Doors

LEARN MORE ABOUT NEXUS REEDED DOORS

Nexus Continuous Bead Doors

Product Education

Nexus Flat Panel Door Style

Raleigh S1000 Nexus Door
S1000 Raleigh
S555 Crawford

Our Nexus Flat Panel Shaker Doors and Drawer Fronts blend classic with contemporary to create a clean, versatile design.

When ordering, please specify the following:

    • Door style NX62 and Drawer Front Style NX62*
    • NP400 Series Nexus Profile – Scroll down to see the options
    • Center Panel Wood Species / Grade and Grain Direction
      • Flat Panel is available with Vertical or Horizontal Grain
    • Stile, Rail, and Outside Edge Molding Wood Species / Grade
    • Order unfinished or choose a finish option from Chapter R

Nexus Flat Panel Profile Options

Nexus Cabinet Doors and Drawer Fronts are only available in the thickness indicated within the individual profile drawings. The flat center panel is available in 1/2″ thick plywood with wood veneer face/back with MDF core or raw MDF for painted products.

NP401

Minimum Door / Drawer Front Size:
4 3/4″ x 4 3/4″

Nexus Profile NP401

NP411

Minimum Door / Drawer Front Size:
5″ x 5″

Nexus Profile-NP411

NP402

Minimum Door / Drawer Front Size:
5 1/4″ x 5 1/4″

Nexus Profile NP402

NP403

Minimum Door / Drawer Front Size:
5 1/2″ x 5 1/2″

Nexus Profile NP403

NP412

Minimum Door / Drawer Front Size:
5 3/4″ x 5 3/4″

Nexus Profile-NP412

NP404

Minimum Door / Drawer Front Size:
6″ x 6″

Nexus Profile NP404

NP413

Minimum Door / Drawer Front Size:
4 3/4″ x 4 3/4″

Nexus Profile NP413

NP414

Minimum Door / Drawer Front Size:
5 1/4″ x 5 1/4″

Nexus Profile NP414

NP405

Minimum Door / Drawer Front Size:
5 1/4″ x 5 1/4″

Nexus Profile NP405

NP406

Minimum Door / Drawer Front Size:
6″ x 6″

Nexus Profile NP406

NP407

Minimum Door / Drawer Front Size:
5 1/8″ x 5 1/8″

Nexus Profile NP407

NP408

Minimum Door / Drawer Front Size:
4 3/4″ x 4 3/4″

Nexus Profile NP408

NP409

Minimum Door / Drawer Front Size:
5″ x 5″

Nexus Profile NP409

NP410

Minimum Door / Drawer Front Size:
5 1/4″ x 5 1/4″

Nexus Profile NP410

Nexus Reeded Door Style

S1005 Albany White Oak Reeded Door
S1005 Albany
S1010 Caldwell Reeded Cabinet Door
S1010 Caldwell

Our made-to-order Nexus Doors with Reeded (Beaded) Applied Molding provide an easy way to add texture and visual interest to custom furniture, islands, vanities, and more.

When ordering, please specify the following:

    • Door style NX62 and Drawer Front Style NX62*
    • NP500 Series Nexus Profile – Scroll down to see the options
    • Center Panel Wood Species / Grade and Grain Direction
    • Stile, Rail, and Outside Edge Molding Wood Species / Grade
    • Reeded Molding #3241 or #3215 with choice of Wood Species / Grade and direction of the molding. Molding can be placed Vertical (top to bottom) or Horizontal (left to right)
      • When running the applied molding vertically, the overall width of the door or drawer front will only be available in ¼” increments
      • When running the applied molding horizontally, the overall height of the door or drawer front will only be available in ¼” increments
    • Order unfinished or choose a finish option from Chapter R
    •

Nexus Reeded Profile Options

Nexus doors and drawer fronts with Reeded Molding are only available in the thickness indicated within the individual profile drawings. The flat center panel is available in 1/2″ thick plywood with wood veneer face/back with MDF core or raw MDF for painted products. Our Reeded Applied Molding is applied to the face of the door or drawer front.

NP502 with Reeded Applied Molding

Minimum Door / Drawer Front Size: 4 3/4″ x 4 3/4″

Nexus Profile NP502 with AM3241
Nexus Profile NP502 with AM3215

NP501 with Reeded Applied Molding

Minimum Door / Drawer Front Size: 5″ x 5″

Nexus Profile NP501 with AM3241
Nexus Profile NP501 with AM3215

NP504 with Reeded Applied Molding

Minimum Door / Drawer Front Size: 4 3/4″ x 4 3/4″

Nexus Profile NP504 with AM3241
Nexus Profile NP504 with AM3215

NP503 with Reeded Applied Molding

Minimum Door / Drawer Front Size: 5 1/2″ x 5 1/2″

Nexus Profile NP503 with AM3241
Nexus Profile NP503 with AM3215
