Traditional Mortise & Tenon Cabinet Doors

Traditional Mortise & Tenon Doors are the most popular type of cabinet door construction within the woodworking industry. This method of construction is standard in many kitchen designs, refacing projects, furniture pieces, and other applications because of its flexibility in design, ranging anywhere from simple to complex and contemporary to traditional.

WalzCraft Traditional Mortise & Tenon Doors can be ordered in many ways. Our commitment to offering a large variety of features allows the highest level of customization within the industry. Traditional door styles most commonly have a solid wood raised or veneered flat center panel with a square or arched top design. Alternative features include prepped for glass (designer glass is also available), applied moldings, mullion designs, lattice center panels, wire mesh grilles, and louvers. Please visit WalzCraft’s link to Accent Cabinet Doors for additional information and available options.

Traditional Mortise & Tenon Door StylesWood Species OptionsDoor Profile OptionsDesign Options for Cabinet DoorsValue Added Cabinet Door FeaturesCabinet Door Frame and Mullion Options5-Piece MDF Cabinet DoorsCurved Cabinet DoorsFinishing Options for Cabinet Doors and Componets

divider top

Traditional Mortise & Tenon Door Styles



Mortise & Tenon Door Styles

Solid Wood Door Styles

The Door Style is the basic shape of the frame of the door. WalzCraft offers all of the most common square, arch and liberty designs in many configurations. Our standard offering also includes many rare styles that can help create a lasting and unique product.

View all of WalzCraft’s Solid Wood Mortise & Tenon Door Styles.

Veneer Flat Panel Door Styles

Our standard offering of Veneered Flat Panel Door Styles includes the popular square, arched and many other unique styles. The distinguishing factor of the these Door Styles is that the center panel is a 1/4” thick flat veneer panel.

View all of WalzCraft’s Veneer Flat Panel Mortise & Tenon Door Styles.





Back to Top Back to Top ▲

Profile Options for Mortise & Tenon Doors

Cabinet Door Profile Options

View Stile and Rail Profiles for Mortise and Tenon Cabinet Doors View Center Panel Profiles for Cabinet Doors View Outisde Edge Profile options

The three main profiles of Mortise & Tenon Door Styles are the Stile & Rail Profile, Center Panel Profile, and Outside Edge Profile. Veneer Flat Panel Door Styles do not use a Center Panel Profile because they are built with a 1/4″ flat veneered center panel. In addition to these profile options, WalzCraft offers several other design options that will allow you to enhance the appearance of a cabinet door.



Stile and Rail Profiles

The Stile & Rail Profile is the inside profile (or detail) for the frame of the cabinet door. Another name for this profile is the Cope & Stick Profile of the inside edge.

WalzCraft offers over 50 different designs of Stile & Rail Profiles as well as matching profiles that are designed for a glass insert. Beyond the more traditional designs are Mirrored Joint Profiles, Old World Profiles, and profiles engineered to be used with Applied Molding.

View Stile & Rail Profiles

Center Panel Profile Options

The Center Panel Profile is the design around the perimeter of the center panel. WalzCraft offers many varieties of raised, flat (reverse) solid wood, and recessed center panel profiles.

Most profiles are displayed in families of similar design with different reveals, which allows you to maintain the same profile design for small components like drawer fronts.

The PR324-10 profile allows you to create a flat panel look with a solid wood center panel (reversed center panel).

View Center Panel Profiles

Outside Edge Profile Options

The Outside Edge Profile is the design around the outer perimeter of the cabinet door frame.

In our 150+ Outside Edge Profiles you will find:

  • Basic square edge (D7)
  • Square edges with a bevel for doors used in Inset Cabinetry
  • Profiles with a lip to be used in place of handles or knobs
  • Applied Molding edges
  • Many more selections

View Outside Edge Profiles

Back to Top ▲

Design Enhancements for Mortise & Tenon Doors

Enhancing the appearance of any cabinet door is easy with these supplementary design options. Click on the images below to learn more about each design option.

Applied MoldingStile and Rail WidthsCenter Panel Face RoutingStile and Rail Face Routing

Applied Mullion PatternsDecorative InsertsMirror JointsCenter Panel Design Patterns

Alternative features such as frame & mullion/muntin doors prepped for glass, designer and leaded glass, wood lattice center panels, wire mesh grilles, and louvers are great cabinet door enhancements as well. Learn more about these options on our Accent Cabinet Doors Page.

Back to Top ▲

Value Added Cabinet Door Features



Finish Sanding

The WalzCraft standard is to finish / fladder sand all of its products to at least a 180 grit finish sand. Most WalzCraft doors are orbital sanded on both the front and back sides. All cross grain scratches are removed from the face of each door. Each door is then fladder sanded / denibbed on the front and backsides to remove any raised grain and to lightly break any sharp edges. This results in minimal prep work upon delivery for in house prefinishing.

All Finish Sanding is included at no additional charge.

Learn more about sanding and recommended prep work.

Flexible Stile & Rail Width

Traditional construction also allows the added benefit of customizing Stile & Rail widths beyond the 2 ¼” standard, to allow for a higher end look without added cost. Reducing Stile & Rail widths on Traditional, Old World, Mitered and MDF/RTF doors gives you the ability to order doors smaller than the printed minimum size.

The following Stile & Rail part sizes for Traditional, Old World, Mitered and MDF/RTF products will not be subject to additional charges: 1½”, 1¾”, 2″, 2¼”, 2½”, 2¾”, 3″, 3¼”, 3½”, 3¾”, 4″, 4¼”, 4½”, 4¾”, 5″, 5¼”, 5½”, 5¾”, 6″, 7″, 8″, 9″ and 10″.

Pinless

WalzCraft’s Traditional Mortise & Tenon Doors are professionally crafted using a ‘pinless’ construction method, providing a more organic look and eliminating the use of pins in door joints – ultimately providing the highest level of cabinet door available.

Learn More

Design Flexibility

Traditional Stile & Rail, Center Panel, and Outside Edge options can be interchanged at no additional cost, with a door style number designated for each door style.

Traditional door styles are available in many standard and exotic wood species, and are priced by door style and specie chosen.

Consistent Sizing

WalzCraft warrants the outside dimensions of all products to be within a size tolerance of +/- 1mm. All component parts of an assembled product will have a size tolerance of +/- 2mm.

3/4″ Center Panel

All 3/4″ thick solid wood center panels sit flush with Stiles & Rails on both the front and back sides of the door.

Expedite/Remake

When placing an order with WalzCraft, you have the option to run product through the manufacturing process under our (SL) Standard Lead Time Schedule or our (EX) Expedited Schedule.

If WalzCraft makes a mistake on your order we will expedite those items, by producing them on our Expedited Order Schedule. Replacement items are then shipped out to you, via the shipping method originally elected for the order, at no additional charge.

Samples

If you are interested in seeing a particular door style, wood specie, grade or finish color, we suggest ordering a sample that can be taken to your job site. Discounts may be granted on single samples and displays for showrooms. We reserve the right to limit sample and display orders based on your annual purchases.

Customer Service

Our friendly Customer Support Team is available to answer any questions you may have from 7:00 am – 4:30 pm every work day.
